Pulse Vacuum Automatic Sterilizer

The Pulse Vacuum Automatic Sterilizer are assembled with heating system, microcomputer controlled system, over heat and over pressure protection system, which are reliable for the sterilizing effect.

Send Inquiry

Product Description

Pulse Vacuum Automatic Sterilizer


Pulse Vacuum Automatic Sterilizer



Use


The Pulse Vacuum Automatic Sterilizers are assembled with heating system, microcomputer controlled system, over heat and over pressure protection system, which are reliable for the sterilizing effects, convenient of operation and energy conservation. Pulse Vacuum Automatic Sterilizer are ideal equipments for clinics, scientific research institutes and other organizations to sterilizer surgical instruments, fabrics, glasses, culture media etc.



Characteristics of Pulse Vacuum Automatic Sterilizer

• Microcomputer controlled, digital display of working statues, touch type key.

• Pulse Vacuum Automatic Sterilizer dynamically shows the temperature, pressure time ,vacuum rate and the cycle status.

• With fully automatically route of the water inlet, pulse vacuum, heating. sterilizing,

• draining. exhausting and vacuum drying.

• 3 times pulse vacuum, the vacuum rate would reach -0.081mpa after that, which ensure the completely extracting of inner air from the dressing and A,B type hollowed appliance.

• With 4 fixed programs for the appliance, medical dressing, rubber and fluid, the user also could set the program as they need randomly.

• Equipped with the PY/TT testing connector, easy for running the testing.

• Multiple pulse vacuum drying after sterilizing. which ensure the good sterilizing result.

• Equipped with 0.22pum bacteria filter, it ensure the air which enter the inner vacuumed chamber is sterile. avoid the second time contamination.

• Hand wheel type for quick- -open the door. Self inflating type seal.

• Pulse Vacuum Automatic Sterilizer is adopted with immersed heating tube, with high heating efficiency.

• Steam-water inner circulation system: no steam discharge. and the

• environment for the sterilizing will be clean and dry.

• Automatically shut off with beep reminding after sterilization.

• Fully high quality stainless, equipped with double stainless steel baskets.



Technical Data of Pulse Vacuum Automatic Sterilizer


MODEL

LS-50HV

LS-75HV

LS-100HV

Technical Data

Chamber volume

50L

φ340×550mm

75L

φ400×600mm

100L

φ440×650mm

Working pressure

0.22Mpa

Working temperature

134℃

Max. working pressure

0.23Mpa

Heat average

≤±1℃

Timer range

0-99min

Temperature adjust range

0-134℃

Power

3000W/AC220V 50HZ

4500W/AC220V 50HZ

4500W/AC220V 50HZ

Overall dimension(mm)

690×470×1140

730×510×1270

750×550×1305

Transport dimension(mm)

760×550×1290

820×600×1380

840×640×1410

G.W/N.W

120Kg/100Kg

140Kg/118Kg

160Kg/128Kg
