Ultraviolet Water Autoclave

The Ultraviolet Water autoclave adopts a special high strength non ozone ultraviolet sterilizing lamp and an inner wall after the special treatment of micro carbon smelly martensitic stainless steel barrel, outer side of

Send Inquiry

Product Description

Ultraviolet Water Autoclave


Ultraviolet Water Autoclave



UV WATER STERILIZER


16W 2GPM /25W 6GPM/30W 8GPM/ 40W 10GPM/55W 12GPM

Working Principle:

The Ultraviolet Water autoclave adopts a special high strength non ozone ultraviolet sterilizing lamp and an inner wall after the special treatment of micro carbon smelly martensitic stainless steel barrel, outer side of the barrel body with a special polishing treatment the pretreated water flowing in the tube when subjected to ultraviolet 253.7nm enough line volume of irradiation, has good sterilizing effect, but also effectively reduces the influence of ultra pure water.


What’s UVC sterilization?



We've all heard of UV-A and UV-B ultraviolet rays: they come from the sun, and they're the reason we have SPF ratings on sunscreen. Less publicly known, but effective in it's own right is the UV-C subsection of the light spectrum.



UV-C is a shorter wave ultraviolet radiation, and it can destroy bacteria, viruses, spores (including C. diff.) and other pathogens in the air, in liquids, or on surfaces. UV-C has been used in germicidal applications since the 1930's.


How does UV-C kill microorganisms?


UV-C destroys the DNA of germs and pathogens when emitted at a wavelength of 253.7 nanometers. Once the DNA is broken, it loses it's ability to reproduce and the bacteria or virus itself is rendered harmless.



Ultraviolet Water AutoclaveUltraviolet Water Autoclave


Model No.

Power

Flow Rate

Inlet/Outlet

Operation Pressure

Product Size

PHIYANG-016

16W

2GPM(0.4m³/hr)

1/2"male

10bar(145psi)

370*φ63.5

PHIYANG-025

25W

6GPM(1.4m³/hr)

1/2"male

10bar(145psi)

590*φ63.5

PHIYANG-030

30W

8GPM(1.8m³/hr)

3/4"male

10bar(145psi)

910*φ63.5

PHIYANG-040

40W

10GPM(2.3m³/hr)

3/4"male

10bar(145psi)

885*φ63.5

PHIYANG-055

55W

12GPM(2.7m³/hr)

3/4"male

10bar(145psi)

950*φ63.5


Feature ofUltraviolet Water autoclave


•304 polished stainless steel reactor
•Quartz sleeve ensure the best working temperature
•Comprehensive,rapid and efficient sterilization, sterilization, the highest rate is 99.9%, higher output, physical sterilization, No side effects, n no secondary pollution
•All stainless steel shell, the European technology, smooth inner wall. Not Blind Angle.
•Clean equipment,electroplating polishing,applicable to high purifying environment
•The electrical device is configured to the world market
•Special design, more convenient


Application scope ofUltraviolet Water autoclave


•Food processing industrial water disinfection, including juice, milk, beverage, beer, edible oil, and various kinds of canned products such as cold drink, water disinfection
•Electronic industry use the ultra pure water

•Ultraviolet Water autoclave can be used in hospital, all kinds of laboratory water disinfection, and the high content to a causative agent waste water disinfection

•Application water disinfection, including residents resident buildings, residential, office buildings, hotels, restaurants, tap water factory, etc
•Aquatic product processing purification disinfection, shellfish purification disinfection, fish processing purification disinfection,ect.
•Military camps, the water supply system
•Urban waste water disinfection, maximum capacity can reach above 1 million tons per day
•Ultraviolet Water autoclave can be used in swimming pools, water other entertainment water disinfection.
•Cooling water disinfection, including power plant, nuclear power plant cooling water, industrial production cooling water, the central air conditioning system cooling water
•Biological, chemical medicine, cosmetics production with cooling water
•Sea water, fresh water nursery, breeding (fish, eels, shrimp, abalone, shellfish, etc) water, total processing water can reach above 200000 tons per day
•Ultraviolet Water autoclave can be used in agricultural water disinfection, including water and irrigation, greenhouse,ect.
